Laser cutting technology is widely used in the processing of metal and non-metal materials, which can greatly reduce processing time, reduce processing costs and improve workpiece quality. Modern lasers have become a fantasy pursuit The "sword" that "shaves iron like mud". Taking the CO2 laser cutting machine as an example, the entire system consists of a control system, motion system, optical system, water cooling system, smoke exhaust and air blowing protection system, etc. It adopts advanced CNC mode to achieve multi-axis linkage and equal energy cutting of laser without being affected by speed. It also supports graphics formats such as DXP, PLT, and CNC and strengthens interface graphics drawing and processing capabilities Good motion accuracy in high speed state is achieved by using imported servo motor and transmission guide structure with superior performance.
Laser cutting is achieved by applying the high power density energy generated after laser focusing. Under the control of the computer, the laser is discharged by pulses, thereby outputting controlled repetitive high-frequency pulsed laser light to form a beam of a certain frequency and pulse width. The pulsed laser beam is conducted and reflected by the optical path and focused on the surface of the processed object through a focusing lens group to form fine, high-energy-density light spots. The focus spots are located near the surface to be processed Melting or gasifying the material being processed at instant high temperatures. Each high-energy laser pulse instantly sputters a small hole into the surface of the object. Under computer control, the laser processing head and the processed material perform continuous relative motion and dotting according to the pre-drawn figure, so that the object will be processed into the desired shape. When cutting , a gas flow coaxial with the beam is ejected from the cutting head, blowing the melted or vaporized material out from the bottom of the cut (Note: If the blown gas and the cut material react thermally, this reaction will provide additional energy required for cutting; the gas flow also has the effect of cooling the cut surface, reducing the heat-affected zone and ensuring that the focusing mirror is not contaminated). Compared with traditional plate processing methods, laser cutting has high cutting quality (narrow cut width, small heat-affected zone, smooth cut), high cutting speed, and high flexibility (can cut any shape at will), extensive material adaptability and other advantages.Shenzhen Xinyize Technology Co, Ltd accurately process laser cutting parts of various materials for you!
